安裝類型 |
機架式 |
|
高度 |
4U |
|
POWER7+ 處理器 |
8 個 3.5 GHz POWER7+ 處理器內核或 |
|
8 個 4.0 GHz POWER7+ 處理器內核 |
|
CPU個數 |
1 至 4 個 |
|
二級 （L2） 緩存 |
每個內核 256 KB 二級緩存 |
|
三級 （L3） 緩存 |
每個內核 10 MB 三級緩存 （eDRAM） |
|
內存 |
高達 1 TB 的 1066 MHz DDR3 加上 |
|
帶有硬件輔助的 Active Memory Expansion |
|
集成的 SAS 托架，適合固態驅動器 （SSD）或硬盤驅動器 |
六個 SFF SAS 驅動器托架 |
|
集成的介質托架 |
1 個用于 SATA DVD-RAM 的 Slimline 托架 |
|
集成的 PCI 適配器插槽 |
6 個 PCIe （8x） 第 2 代插槽 |
|
標準以太網端口 |
雙 10 Gb 加上選擇兩個額外的 10 Gb 或兩個額外的 1 Gb |
|
集成的 SAS 控制器 |
2 個 SAS DASD/SSD 控制器 |
|
其他集成端口 |
3 個 USB 端口，2 個 HMC 端口，2 個 SPCN 端口，1 個串行端口 |
|
GX 插槽 （12X） |
2 個 |
|
擴展功能（可選） |
|
|
I/O 擴展 |
多達 4 個 PCIe 12X I/O 抽屜 |
|
PCI 適配器 |
6 Gb 和 3 Gb SAS RAID |
|
16 Gb、8 Gb 和 4 Gb 光纖通道 |
|
10 Gb 和 1 Gb 以太網 |
|
10 Gb 融合網絡（以太網 |
|
光纖通道） |
|
40 Gb QDR IB |
|
WAN/Async、USB、加密、SSD |
|
I/O 擴展：適用于 HDD/SSD 的 SAS SFF 托架 |
存儲抽屜中多達 1334 個托架（最多 56 個抽屜） |
|
PCIe 12X I/O 抽屜中多達 72 個托架 |
|
I/O 擴展：EXP30 Ultra SSD 抽屜 |
多達 2 個抽屜（最高 960k IOPS（只讀）） |
|
多達 60 個 SSD（最高 23.2 TB 容量） |
|
PowerVM 技術 |
|
|
POWER Hypervisor™ |
LPAR、動態 LPAR、虛擬 LAN（內存到內存分區間通訊） |
|
PowerVM 標準版（可選） |
PowerVM ，外加 Micro-Partitioning™，每個處理器最多 20 個微分區；多個共享處理器池；共享專用容量；虛擬 I/O 服務器 |
|
PowerVM 企業版（可選） |
PowerVM 標準版，外加實時分區遷移 （LPM） 和 Active Memory Sharing （AMS） |
|
RAS 功能 |
處理器指令重試 |
|
備用處理器恢復 |
|
可選擇動態固件更新 |
|
Chipkill 內存 |
|
ECC 二級緩存，三級緩存 |
|
帶故障監控功能的服務處理器 |
|
熱插拔磁盤托架 |
|
熱插拔/盲交換 PCI 插槽 |
|
熱插拔冗余電源和散熱風扇 |
|
動態處理器取消分配 |
|
PCI 插槽上的擴展錯誤處理 |
|
操作系統1 |
AIX、IBM i 和 Linux for POWER® |
|
高可用性 |
IBM PowerHA® 系列 |
|
電源要求 |
200 V 到 240 V AC，單相 |
|
系統規格 |
機架抽屜：8.55 英寸（高）x 17.6 英寸（寬）x 33.78 英寸（深）（217 厘米 x 447 厘米 x 858 厘米）；重量：155 磅（70.3 千克）2 |
Processor
(#EPT7) -4.0 GHz, 8-core POWER7+ Processor DCM (2x4-core)
(#EPT8) -3.5 GHz, 8-core POWER7+ Processor DCM (2x4-core)
Memory
(#EM01) -Memory Riser Card
(#EM08) -8GB (2x4GB) Memory DIMMs, 1066 MHz, 2Gb DDR3 DRAM
(#EM4B) -16GB (2x8GB) Memory DIMMs, 1066 MHz, 4Gb DDR3 DRAM
(#EM4C) -32GB (2x16GB) Memory DIMMs, 1066 MHz, 4Gb DDR3 DRAM
Disk
(#1737) -856GB 10k RPM SAS SFF Disk Drive (IBM i)
(#1738) -856GB 10k RPM SAS SFF-2 Disk Drive (IBM i)
(#1751) -900GB 10K RPM SAS SFF Disk Drive (AIX/Linux)
(#1752) -900GB 10k RPM SAS SFF-2 Disk Drive (AIX/Linux)
(#1790) -600GB 10K RPM SAS SFF Disk Drive (AIX/Linux)
(#1817) -Quantity 150 of #1962
(#1818) -Quantity 150 of #1964
(#1844) -Quantity 150 of #1956
(#1866) -Quantity 150 of #1917
(#1868) -Quantity 150 of #1947
(#1869) -Quantity 150 of #1925
(#1879) -283GB 15K RPM SAS SFF Disk Drive (IBM i)
(#1880) -300GB 15K RPM SAS SFF Disk Drive (AIX/Linux)
(#1882) -146.8GB 10K RPM SAS SFF Disk Drive
(#1883) -73.4 GB 15K RPM SAS SFF Disk Drive
(#1884) -69.7 GB 15K RPM SAS SFF Disk Drive
(#1885) -300GB 10K RPM SFF SAS Disk Drive
(#1886) -146GB 15K RPM SFF SAS Disk Drive (AIX/Linux)
(#1888) -139GB 15K RPM SFF SAS Disk Drive (IBM i)
(#1891) -Quantity 150 of #1883
(#1899) -Quantity 150 of #1882
(#1911) -283GB 10K RPM SFF SAS Disk Drive (IBM i)
(#1916) -571GB 10k RPM SAS SFF Disk Drive (IBM i)
(#1917) -146GB 15k RPM SAS SFF-2 Disk Drive (AIX/Linux)
(#1925) -300GB 10k RPM SAS SFF-2 Disk Drive (AIX/Linux)
(#1926) -Quantity 150 of #1879
(#1927) -Quantity 150 of #1948
(#1928) -Quantity 150 of #1880
(#1929) -Quantity 150 of #1953
(#1947) -139GB 15k RPM SAS SFF-2 Disk Drive (IBM i)
(#1948) -283GB 15k RPM SAS SFF-2 Disk Drive (IBM i)
(#1953) -300GB 15k RPM SAS SFF-2 Disk Drive (AIX/Linux)
(#1956) -283GB 10k RPM SAS SFF-2 Disk Drive (IBM i)
(#1962) -571GB 10k RPM SAS SFF-2 Disk Drive (IBM i)
(#1964) -600GB 10k RPM SAS SFF-2 Disk Drive (AIX/Linux)
(#3646) -73GB 15K RPM SAS Disk Drive
(#3647) -146GB 15K RPM SAS Disk Drive (AIX/Linux)
(#3648) -300GB 15K RPM SAS Disk Drive (AIX/Linux)
(#3649) -450GB 15K RPM SAS Disk Drive (AIX/Linux)
(#3658) -428GB 15K RPM SAS Disk Drive (IBM i)
(#3676) -69.7GB 15k rpm SAS Disk Drive
(#3677) -139.5GB 15k rpm SAS Disk Drive (IBM i)
(#3678) -283.7GB 15k rpm SAS Disk Drive (IBM i)
(#7517) -Quantity 150 of #3676
(#7518) -Quantity 150 of #3677
(#7519) -Quantity 150 of #3678
(#7538) -Quantity 150 of #3658
(#7543) -Quantity 150 of #1884
(#7544) -Quantity 150 of #1888
(#7547) -Quantity 150 of #1885
(#7548) -Quantity 150 of #1886
(#7549) -Quantity 150 of #3647
(#7550) -Quantity 150 of #1790
(#7557) -Quantity 150 of #1911
(#7564) -Quantity 150 of #3648
(#7565) -Quantity 150 of #3649
(#7566) -Quantity 150 of #1916
(#ELS1) -#ES11 Load Source Specify (387GB SSD SFF-1)
(#ELSJ) -#ESDJ Load Source Specify (571GB 15K RPM SFF-1 )
(#ELSN) -#ESDN Load Source Specify (571GB 15K RPM SFF-2 )
(#ELS9) -#ES1A Load Source Specify (387GB SSD SFF-2)
(#EQ37) -Quantity 150 of #1737 (856GB SFF-1 disk)
(#EQ38) -Quantity 150 of #1738 (856GB SFF-2 disk)
(#EQ52) -Quantity 150 of #1752 (900GB SFF-2 disk)
(#EQD2) -Quantity 150 of #ESD2 (1.1TB 10k SFF-2)
(#EQD3) -Quantity 150 of #ESD3 (1.2TB 10k SFF-2)
(#ESD0) -1.1TB 10K RPM SAS SFF-1 Disk Drive (IBM i)
(#ESD1) -1.2TB 10K RPM SAS SFF-1 Disk Drive (AIX/Linux)
(#ESD2) -1.1TB 10K RPM SAS SFF-2 Disk Drive (IBMi)
(#ESD3) -1.2TB 10K RPM SAS SFF-2 Disk Drive (AIX/Linux)
(#EQDN) -Quantity 150 of #ESDN (571GB 15K RPM SAS SFF-2 for IBM i)
(#EQDP) -Quantity 150 of #ESDP (600GB 15K RPM SAS SFF-2 for AIX/ LINUX)
(#ESDJ) -571GB 15K RPM SAS SFF-1 Disk Drive - 528 Block (IBM i)
(#ESDK) -600GB 15K RPM SAS SFF-1 Disk Drive - 5xx Block (AIX/Linux)
(#ESDN) -571GB 15K RPM SAS SFF-2 Disk Drive - 528 Block
(#ESDP) -600GB 15K RPM SAS SFF-2 Disk Drive - 5xx Block
Solid State Drive
(#0893) -#ES0B Load Source Specify
(#0894) -#ES0D Load Source Specify
(#1775) -177GB SFF-1 SSD w/ eMLC (AIX/Linux)
(#1787) -177GB SFF-1 SSD w/ eMLC (IBM i)
(#1793) -177GB SFF-2 SSD w/ eMLC (AIX/Linux)
(#1794) -177GB SFF-2 SSD w/ eMLC (IBM i)
(#1887) -Quantity 150 of #1793
(#1958) -Quantity 150 of #1794
(#1995) -177GB SSD Module with eMLC (AIX/Linux)
(#1996) -177GB SSD Module with eMLC (IBM i)
(#3586) -69GB 3.5" SAS Solid State Drive
(#3587) -69GB 3.5" SAS Solid State Drive
(#7535) -Quantity 150 of #3586
(#7536) -Quantity 150 of #3587
(#7578) -QTY 150, 177GB SFF-1 SSD w/ eMLC (AIX/Linux)
(#7582) -QTY 150, 177GB SFF-1 SSD w/ eMLC (IBM i)
(#EH10) -387GB SFF-2 SSD converted for AIX/Linux
(#EH11) -387GB SFF-2 SSD converted for AIX/Linux
(#EH12) -387GB SFF-2 SSD converted for IBM i
(#EH13) -387GB SFF-2 SSD converted for IBM i
(#EH14) -GEN2-S Conversion Carrier for Feature ES0C 387GB SSD
(#EH15) -Qty 150 Gen2-S Conversion Carriers for feature EQ0A 387GB SSD.
(#EH16) -GEN2-S Conversion Carrier for Feature ES0D 387GB SSD (IBM i)
(#EH17) -Qty 150 GEN2-S Conversion Carriers for Feature EQ0B 387GB SSD (IBM i)
(#ELSF) -#ES0F Load Source Specify (775GB SSD SFF-1)
(#ELSH) -#ES0H Load Source Specify (775GB SSD SFF-2)
(#ELSK) -#ES0K Load Source Specify (387GB 1.8" SSD for IBM i)
(#ELT9) -#ES79 Load Source Specify (387GB SFF-2 SSD 5xx for IBM i)
(#ELTF) -#ES7F Load Source Specify (775GB SFF-2 SSD 5xx for IBM i)
(#EQ0A) -Quantity 150 of #ES0A
(#EQ0B) -Quantity of 150 #ES0B
(#EQ0C) -Quantity of 150 #ES0C
(#EQ0D) -Quantity of 150 #ES0D
(#EQ0G) -Quantity 150 of #ES0G (775GB SSD SFF-2)
(#EQ0H) -Quantity 150 of #ES0H (775GB SSD SFF-2)
(#EQ19) -Quantity 150 of #ES19 (387GB SSD SFF-2)
(#EQ1A) -Quantity 150 of #ES1A (387GB SSD SFF-2)
(#EQ78) -Quantity 150 of #ES78 387GB SFF-2 SSD 5xx
(#EQ79) -Quantity 150 of #ES79 387GB SFF-2 SSD 5xx
(#EQ7E) -Quantity 150 of #ES7E 775GB SFF-2 SSD 5xx
(#EQ7F) -Quantity 150 of #ES7F 775GB SFF-2 SSD 5xx
(#ES02) -387GB 1.8" SAS SSD for AIX/Linux with eMLC
(#ES04) -387GB 1.8" SAS SSD for IBM i with eMLC
(#ES09) -IBM Flash Adapter 90 (PCIe2 0.9TB)
(#ES0A) -387GB SFF-1 SSD for AIX/Linux with eMLC
(#ES0B) -387GB SFF-1 SSD for IBM i with eMLC
(#ES0C) -387GB SFF-2 SSD for AIX/Linux with eMLC
(#ES0D) -387GB SFF-2 SSD for IBM i with eMLC
(#ES0E) -775GB SFF-1 SSD for AIX/Linux
(#ES0F) -775GB SFF-1 SSD for IBM i
(#ES0G) -775GB SFF-2 SSD for AIX/Linux
(#ES0H) -775GB SFF-2 SSD for IBM i
(#ES0J) -387GB 1.8" SSD for AIX/Linux
(#ES0K) -387GB 1.8" SSD for IBM i
(#ES10) -387GB SFF-1 SSD for AIX/Linux
(#ES11) -387GB SFF-1 SSD for IBM i
(#ES19) -387GB SFF-2 SSD for AIX/Linux
(#ES1A) -387GB SFF-2 SSD for IBM i
(#ES78) -387GB SFF-2 SSD 5xx eMLC4 for AIX/Linux
(#ES79) -387GB SFF-2 SSD 5xx eMLC4 for IBM i
(#ES7E) -775GB SFF-2 SSD 5xx eMLC4 for AIX/Linux
(#ES7F) -775GB SFF-2 SSD 5xx eMLC4 for IBM i
Adapters
(#1768) -Integrated Multifunction card with Copper SFP+
(#1769) -Integrated Multifunction card with SR Optical
(#1808) -GX++ 12X DDR Adapter, Dual-port
(#1914) -GX++ 2-port PCIe2 x8 Adapter
(#2055) -PCIe RAID & SSD SAS Adapter 3Gb w/ Blind Swap Cassette
(#2728) -4 port USB PCIe Adapter
(#4808) -PCIe Crypto Coprocessor Gen3 BSC 4765-001
(#4809) -PCIe Crypto Coprocessor Gen4 BSC 4765-001
(#5285) -PCIe2 2-Port 4X IB QDR Adapter 40Gb
(#5287) -PCIe2 2-port 10GbE SR Adapter
(#5288) -PCIe2 2-Port 10GbE SFP+Copper Adapter
(#5289) -2 Port Async EIA-232 PCIe Adapter
(#5646) -Blind Swap Type III Cassette-PCIe, Short Slot
(#5647) -Blind Swap Type III Cassette-PCI-X or PCIe, Standard Slot
(#5662) -175MB Cache RAID - Dual IOA Enablement Card
(#5708) -10Gb FCoE PCIe Dual Port Adapter
(#5717) -4-Port 10/100/1000 Base-TX PCI Express Adapter
(#5729) -PCIe2 8Gb 4-port Fibre Channel Adapter
(#5732) -10 Gigabit Ethernet-CX4 PCI Express Adapter
(#5735) -8 Gigabit PCI Express Dual Port Fibre Channel Adapter
(#5744) -PCIe2 4-Port 10GbE&1GbE SR&RJ45 Adapter
(#5745) -PCIe2 4-Port 10GbE&1GbE SFP+Copper&RJ45 Adapter
(#5748) -POWER GXT145 PCI Express Graphics Accelerator
(#5767) -2-Port 10/100/1000 Base-TX Ethernet PCI Express Adapter
(#5768) -2-Port Gigabit Ethernet-SX PCI Express Adapter
(#5769) -10 Gigabit Ethernet-SR PCI Express Adapter
(#5772) -10 Gigabit Ethernet-LR PCI Express Adapter
(#5773) -4 Gigabit PCI Express Single Port Fibre Channel Adapter
(#5774) -4 Gigabit PCI Express Dual Port Fibre Channel Adapter
(#5785) -4 Port Async EIA-232 PCIe Adapter
(#5805) -PCIe 380MB Cache Dual - x4 3Gb SAS RAID Adapter
(#5899) -PCIe2 4-port 1GbE Adapter
(#5901) -PCIe Dual-x4 SAS Adapter
(#5903) -PCIe 380MB Cache Dual - x4 3Gb SAS RAID Adapter
(#5913) -PCIe2 1.8GB Cache RAID SAS Adapter Tri-port 6Gb
(#5923) -Non-paired PCIe SAS RAID Indicator
(#5924) -Non-paired Indicator 5913 PCIe SAS RAID Adapter
(#5925) -Shared EXP30 Indicator
(#5927) -Remote EXP30 Indicator
(#7862) -PCI Blind Swap Cassette Kit, Single Wide Adapters, Type II
(#7863) -PCI Blind Swap Cassette Kit, Double Wide Adapters, Type III
(#EC28) -PCIe2 2-Port 10GbE RoCE SFP+ Adapter
(#EC38) -PCIe3 2-port 10GbE NIC&RoCE SFP+ Copper Adapter
(#EC2J) -PCIe2 2-port 10GbE SFN6122F Adapter
(#EC2K) -PCIe2 2-port 10GbE SFN5162F Adapter
(#EC2N) - PCIe3 2-port 10GbE NIC&RoCE SR Adapter
(#EC30) -PCIe2 2-Port 10GbE RoCE SR Adapter
(#EJ0J) -PCIe3 RAID SAS Adapter Quad-port 6Gb x8
(#EJ0L) -PCIe3 12GB Cache RAID SAS Adapter Quad-port 6Gb x8
(#EJ10) -PCIe3 SAS Tape/DVD Adapter Quad-port 6Gb x8
(#EJ28) -PCIe Crypto Coprocessor Gen3 BSC 4765-001
(#EJ29) -PCIe Crypto Coprocessor Gen4 BSC 4765-001
(#EN0A) -PCIe2 16Gb 2-port Fibre Channel Adapter
(#EN0H) -PCIe2 4-port (10Gb FCoE & 1GbE) SR&RJ45
(#EN0K) -PCIe2 4-port (10Gb FCoE & 1GbE) SFP+Copper&RJ45
(#EN0S) -PCIe2 4-Port (10Gb+1GbE) SR+RJ45 Adapter
(#EN0U) -PCIe2 4-port (10Gb+1GbE) Copper SFP+RJ45 Adapter
(#EN0W) -PCIe2 2-port 10/1GbE BaseT RJ45 Adapter
(#EN10) -Integrated Multifunction Card w/ 10GbE RJ45 & Copper Twinax
(#EN11) -Integrated Multifunction Card w/ 10GbE RJ45 & SR Optical
(#EN13) -PCIe 1-port Bisync Adapter
(#EN14) -PCIe 1-port Bisync Adapter CIM
(#EN27) -2 Port Async EIA-232 PCIe Adapter
(#EN29) -2 Port Async EIA-232 PCIe Adapter
(#ESA1) -PCIe2 RAID SAS Adapter Dual-port 6Gb
(#ESA3) -PCIe2 1.8GB Cache RAID SAS Adapter Tri-port 6Gb CR
Power
(#5532) -System AC Power Supply, 1925 W
(#5160) -Power Dist Unit 1 Phase NEMA
(#5161) -Power Dist Unit 1 Phase IEC
(#5162) -Power Dist Unit 2 of 3 Phase
(#5163) -Power Dist Unit - 3 Phase
(#7109) -Intelligent PDU+, 1 EIA Unit, Universal UTG0247 Connector
(#7188) -Power Distribution Unit
(#EB2N) -DC Power Supply - 1400W (180-400V)
