外形/ 高度 |
機架/4U |
|
處理器（最多） |
多達 4 個高達 3.2GHz 的英特爾 ®至強® E7-4800/8800 v4 處理器系列，高達 1866MHz（DDR4）的內存訪問，每個處理器 24 個內核 |
|
內存（最大） |
高達 6TB，每個CPU板24個內存插槽，最多96 個，支持 64GB LRDIMM 的 DIMM 插槽 |
|
擴展插槽 |
多達 11 個 PCIe；第三代（多達 11 個）、第二代（多達 2 個）、多達 5 個 x16 插槽；多達 6 個全長、全高插槽 |
|
磁盤托架（總數/ 熱插拔） |
最多 8 個 2.5 英寸串行連接 SCSI （SAS）硬盤驅動器（ HDD）或者 SAS 固態硬盤驅動器（ SSD）；或者最多 16 個 1.8 英寸 eXFlash SSD 或最多 4 個 NVMe PCIe SSD |
|
最大內部存儲容量 |
多達 8 個 2.5 英寸 SAS/SATA 硬盤驅動器（ HDD）或多達 8 個 2.5 英寸 SSD 或多達 16個 1.8 英寸 eXFlash SSD 或多達 4 個 2.5 英寸 NVMe PCIe SSD |
|
網絡接口 |
一個 ML2 插槽；ML2 卡選項包括：4 個 1GbE 銅纜端口或 2 個 10GbE SFP+ 端口或 2 個10GbE 10BaseT 端口；4 個 10GbE 端口；2 個 40GbE/FDR VPI 適配器；專用的 1GbE 板載管理端口 |
|
電源（標配/ 最大） |
多達 4 個通用型 1400W 或 900W AC 或 4 個 750W DC |
|
熱插拔部件 |
半長 I/O Book、全長 I/O Book、電源、風扇、硬盤驅動器、SSD |
|
RAID 支持 |
標配 RAID 0、1、10；可選 RAID 5、6、50、60 |
|
系統管理 |
Lenovo XClarity、LAN 2 警報、自動服務器重啟、ServerGuide、IMM2、光通路診斷（獨立供電）、LAN 喚醒、動態系統分析、存儲中的預測性故障分析、處理器、適配器插槽、VRM、風扇、電源和內存 |
|
支持的操作系統 |
Microsoft Windows Server、Red Hat Enterprise Linux Server、SUSE Linux Enterprise Server、 VMware vSphere Hyperviso |
MT 3837
CPU
Part number/Feature code/Description(processor installed in a Compute Book)/Memory bus speed (RAS /Performance)/Supported quantities/where used
Intel Xeon E7-4800 v2 processor family (not supported in the x3950 X6)
44X3961 A4B3 X6 Compute Book Intel Xeon E7-4809 v2 6C 1.9GHz 105W 1333 / 1066 MHz 2, 4 A4x
44X3966 A4B4 X6 Compute Book Intel Xeon E7-4820 v2 8C 2.0GHz 105W 1600 / 1066 MHz 2, 4 B1x
44X3971 A4B5 X6 Compute Book Intel Xeon E7-4830 v2 10C 2.2GHz 105W 1600 / 1066 MHz 2, 4 -
44X3976 A4B6 X6 Compute Book Intel Xeon E7-4850 v2 12C 2.3GHz 105W 1600 / 1066 MHz 2, 4 B3x
44X3981 A4B7 X6 Compute Book Intel Xeon E7-4860 v2 12C 2.6GHz 130W 1600 / 1333 MHz 2, 4 C1x
44X3986 A4B8 X6 Compute Book Intel Xeon E7-4870 v2 15C 2.3GHz 130W 1600 / 1333 MHz 2, 4 -
44X3991 A4B9 X6 Compute Book Intel Xeon E7-4880 v2 15C 2.5GHz 130W 1600 / 1333 MHz 2, 4 -
44X3996 A4BA X6 Compute Book Intel Xeon E7-4890 v2 15C 2.8GHz 155W 1600 / 1333 MHz 2, 4 C4x
Intel Xeon E7-8800 v2 processor family (also supported in the x3950 X6)
44X4001 A4BB X6 Compute Book Intel Xeon E7-8850 v2 12C 2.3GHz 105W 1600 / 1066 MHz 2, 4 -
44X4031 A4BH X6 Compute Book Intel Xeon E7-8857 v2 12C 3.0GHz 130W 1600 / 1333 MHz 2, 4 -
44X4011 A4BD X6 Compute Book Intel Xeon E7-8870 v2 15C 2.3GHz 130W 1600 / 1333 MHz 2, 4 -
44X4016 A4BE X6 Compute Book Intel Xeon E7-8880 v2 15C 2.5GHz 130W 1600 / 1333 MHz 2, 4 -
44X4036 A4BJ X6 Compute Book Intel Xeon E7-8880L v2 15C 2.2GHz 105W 1600 / 1333 MHz 2, 4 -
44X4021 A4BF X6 Compute Book Intel Xeon E7-8890 v2 15C 2.8GHz 155W 1600 / 1333 MHz 2, 4 -
44X4026 A4BG X6 Compute Book Intel Xeon E7-8891 v2 10C 3.2GHz 155W 1600 / 1333 MHz 2, 4 -
44X4006 A4BC X6 Compute Book Intel Xeon E7-8893 v2 6C 3.4GHz 155W 1600 / 1333 MHz 2, 4 -
Part number/Feature code/Description/Maximum supported/Models where used
RDIMMs
00D5024 A3QE 4GB (1x4GB, 1Rx4, 1.35V) PC3L-12800 CL11 ECC DDR3 1600MHz LP RDIMM 96 (24 per CPU) -
00D5036 A3QH 8GB (1x8GB, 1Rx4, 1.35V) PC3L-12800 CL11 ECC DDR3 1600MHz LP RDIMM 96 (24 per CPU) A4x, B1x, B3x,C1x, C4x,
46W0672 A3QM 16GB (1x16GB, 2Rx4, 1.35V) PC3L-12800 CL11 ECC DDR3 1600MHz LP RDIMM 96 (24 per CPU) -
LRDIMMs
46W0676 A3SR 32GB (1x32GB, 4Rx4, 1.35V) PC3L-12800 CL11 ECC DDR3 1600MHz LP LRDIMM 96 (24 per CPU) -
46W0741 A451 64GB (1x64GB, 8Rx4, 1.35V) PC3-10600 DDR3 1333MHz LP LRDIMM 96 (24 per CPU) -
Internal storage expansion options
00FE000 A4GX eXFlash 200GB DDR3 Storage DIMM 32
00FE005 A4GY eXFlash 400GB DDR3 Storage DIMM 32
MT 6241
Intel Xeon E7-4800 v4 processors (not supported in the x3950 X6)
00WH302 ATX1 / ATXR X6 Compute Book E7-4809 v4 8C 2.1GHz 20M 115W 20 MB 6.4 GHz TruDDR4 1866 MHz /1333 MHz Y N 14x
00WH306 ATX2 / ATXS X6 Compute Book E7-4820 v4 10C 2.0GHz 25M 115W 25 MB 6.4 GHz TruDDR4 1866 MHz /1333 MHz Y N 24x, E1U
00WH310 ATX3 / ATXT X6 Compute Book E7-4830 v4 14C 2.0GHz 35M 115W 35 MB 8 GHz TruDDR4 1866 MHz /1333 MHz Y Y -
00WH314 ATX4 / ATXU X6 Compute Book E7-4850 v4 16C 2.1GHz 40M 115W 40 MB 8 GHz TruDDR4 1866 MHz /1333 MHz Y Y 44x, E2U
Intel Xeon E7-8800 v4 processors (also supported in the x3950 X6)
00KH384 ATWZ / ATYF X6 Compute Book E7-8855 v4 14C 2.1GHz 35M 140W 35 MB 8 GHz TruDDR4 1866 MHz /1333 MHz Y Y -
00WH322 ATX6 / ATXW X6 Compute Book E7-8860 v4 18C 2.2GHz 45M 140W 45 MB 9.6 GHz TruDDR4 1866 MHz /1600 MHz Y Y 54x
00WH318 ATX5 / ATXV X6 Compute Book E7-8867 v4 18C 2.4GHz 45M 165W 45 MB 9.6 GHz TruDDR4 1866 MHz /1600 MHz Y Y -
00WH326 ATX7 / ATXX X6 Compute Book E7-8870 v4 20C 2.1GHz 50M 140W 50 MB 9.6 GHz TruDDR4 1866 MHz /1600 MHz Y Y -
00WH330 ATX8 / ATXY X6 Compute Book E7-8880 v4 22C 2.2GHz 55M 150W 55 MB 9.6 GHz TruDDR4 1866 MHz /1600 MHz Y Y HANA models
00WH334 ATX9 / ATXZ X6 Compute Book E7-8890 v4 24C 2.2GHz 60M 165W 60 MB 9.6 GHz TruDDR4 1866 MHz /1600 MHz Y Y 94x, E3U
00WH342 ATXB / ATY1 X6 Compute Book E7-8891 v4 10C 2.8GHz 60M 165W 60 MB 9.6 GHz TruDDR4 1866 MHz /1600 MHz Y Y -
00WH346 ATXC / ATY2 X6 Compute Book E7-8893 v4 4C 3.2GHz 60M 140W 60 MB 9.6 GHz TruDDR4 1866 MHz /1600 MHz Y Y -
00YG935 AVR6 / AVR7 X6 Compute Book E7-8894 v4 24C 2.4GHz 60M 165W 60 MB 9.6 GHz TruDDR4 1866 MHz /1600 MHz Y Y -
Intel Xeon E7-4800 v3 processors with support for DDR3 memory (not supported in the x3950 X6)
00ML902 AS7T / AS8H X6 DDR3 Compute Book E7-4809 v3 8C 2.0GHz 115W 20 MB 6.4 GHz DDR3 1333 MHz /1333 MHz Y N D4x
00ML906 AS7U / AS8J X6 DDR3 Compute Book E7-4820 v3 10C 1.9GHz 115W 25 MB 6.4 GHz DDR3 1333 MHz /1333 MHz Y N F1x
00ML910 AS7V / AS8K X6 DDR3 Compute Book E7-4830 v3 12C 2.1GHz 115W 30 MB 8 GHz DDR3 1600 MHz /1333 MHz Y Y -
00ML914 AS7W / AS8L X6 DDR3 Compute Book E7-4850 v3 14C 2.2GHz 115WM 35 MB 8 GHz DDR3 1600 MHz /1333 MHz Y Y F3x
Intel Xeon E7-8800 v3 processors with support for DDR3 memory (also supported in the x3950 X6)
00ML922 AS7X / AS8M X6 DDR3 Compute Book E7-8860 v3 16C 2.2GHz 140W 40 MB 9.6 GHz DDR3 1600 MHz /1600 MHz Y N G1x
00FP692 AS7R / AS8F X6 DDR3 Compute Book E7-8867 v3 16C 2.5GHz 165W 45 MB 9.6 GHz DDR3 1600 MHz /1600 MHz Y N -
00ML926 AS7Y / AS8N X6 DDR3 Compute Book E7-8870 v3 18C 2.1GHz 140W 45 MB 9.6 GHz DDR3 1600 MHz /1600 MHz Y Y -
00ML930 AS7Z / AS8P X6 DDR3 Compute Book E7-8880 v3 18C 2.3GHz 150W 45 MB 9.6 GHz DDR3 1600 MHz /1600 MHz Y Y HANA models
00ML938 AS81 / AS8R X6 DDR3 Compute Book E7-8880L v3 18C 2.0GHz 115W 45 MB 9.6 GHz DDR3 1600 MHz /1600 MHz Y Y -
00ML934 AS80 / AS8Q X6 DDR3 Compute Book E7-8890 v3 18C 2.5GHz 165W 45 MB 9.6 GHz DDR3 1600 MHz /1600 MHz Y Y G3x
00ML942 AS82 / AS8S X6 DDR3 Compute Book E7-8891 v3 10C 2.8GHz 165W 45 MB 9.6 GHz DDR3 1600 MHz /1600 MHz Y Y -
00ML946 AS83 / AS8T X6 DDR3 Compute Book E7-8893 v3 4C 3.2GHz 140W 45 MB 9.6 GHz DDR3 1600 MHz /1600 MHz Y Y -
Intel Xeon E7-4800 v3 processors with support for TruDDR4 memory (not supported in the x3950 X6)
00ML950 AS84 / AS8U X6 DDR4 Compute Book E7-4809 v3 8C 2.0GHz 115W 20 MB 6.4 GHz TruDDR4 1866 MHz /1333 MHz Y N D5x
00ML954 AS85 / AS8V X6 DDR4 Compute Book E7-4820 v3 10C 1.9GHz 115W 25 MB 6.4 GHz TruDDR4 1866 MHz /1333 MHz Y N F2x
00ML958 AS86 / AS8W X6 DDR4 Compute Book E7-4830 v3 12C 2.1GHz 115W 30 MB 8 GHz TruDDR4 1866 MHz /1333 MHz Y Y -
00ML962 AS87 / AS8X X6 DDR4 Compute Book E7-4850 v3 14C 2.2GHz 115W 35 MB 8 GHz TruDDR4 1866 MHz /1333 MHz Y Y F4x
Intel Xeon E7-8800 v3 processors with support for TruDDR4 memory (also supported in the x3950 X6)
00ML970 AS88 / AS8Y X6 DDR4 Compute Book E7-8860 v3 16C 2.2GHz 140W 40 MB 9.6 GHz TruDDR4 1866 MHz /1600 MHz Y Y G2x
00FP696 AS7S / AS8G X6 DDR4 Compute Book E7-8867 v3 16C 2.5GHz 165W 45 MB 9.6 GHz TruDDR4 1866 MHz /1600 MHz Y Y -
00ML974 AS89 / AS8Z X6 DDR4 Compute Book E7-8870 v3 18C 2.1GHz 140W 45 MB 9.6 GHz TruDDR4 1866 MHz /1600 MHz Y Y -
00ML978 AS8A / AS90 X6 DDR4 Compute Book E7-8880 v3 18C 2.3GHz 150W 45 MB 9.6 GHz TruDDR4 1866 MHz /1866 MHz Y Y HANA models
00ML986 AS8C / AS92 X6 DDR4 Compute Book E7-8880L v3 18C 2.0GHz 115 45 MB 9.6 GHz TruDDR4 1866 MHz /1600 MHz Y Y -
00ML982 AS8B / AS91 X6 DDR4 Compute Book E7-8890 v3 18C 2.5GHz 165W 45 MB 9.6 GHz TruDDR4 1866 MHz /1600 MHz Y Y G4x
00ML990 AS8D / AS93 X6 DDR4 Compute Book E7-8891 v3 10C 2.8GHz 165W 45 MB 9.6 GHz TruDDR4 1866 MHz /1600 MHz Y Y -
00ML994 AS8E / AS94 X6 DDR4 Compute Book E7-8893 v3 4C 3.2GHz 140W 45 MB 9.6 GHz TruDDR4 1866 MHz /1600 MHz Y Y -
Part number/Feature code/Description/Maximum supported/Models where used
2400 MHz TruDDR4 RDIMMs and LRDIMMs (for use with E7 v4 processors)
46W0821 ATC8 8GB TruDDR4 Memory (1Rx4, 1.2V) PC4-19200 CL17 2400MHz LP RDIMM 96 (24 per CPU) 14x
46W0829 ATCA 16GB TruDDR4 Memory (2Rx4, 1.2V) PC4-19200 CL17 2400MHz LP RDIMM 96 (24 per CPU) All other v4 models
46W0833 ATCB 32GB TruDDR4 Memory (2Rx4, 1.2V) PC4-19200 CL17 2400MHz LP RDIMM 96 (24 per CPU) 8Cx, 8Fx, 8Hx, 8Jx
46W0841 ATGG 64GB TruDDR4 Memory (4Rx4, 1.2V) PC4-19200 CL17 2400MHz LP LRDIMM 96 (24 per CPU) -
2133 MHz TruDDR4 RDIMMs and LRDIMMs (for use with E7 v3 processors, also supported with E7 v4;00KH391 only supported on certain E7 v3 processors)
46W0788 A5B5 8GB TruDDR4 Memory (1Rx4, 1.2V) PC4-17000 CL15 2133MHz LP RDIMM 96 (24 per CPU) D5x
46W0796 A5B7 16GB TruDDR4 Memory (2Rx4, 1.2V) PC4-17000 CL15 2133MHz LP RDIMM 96 (24 per CPU) F2x, F4x, G2x,G4x
95Y4808 A5UJ 32GB TruDDR4 Memory (2Rx4, 1.2V) PC4-17000 CL15 2133MHz LP RDIMM 96 (24 per CPU) -
00KH391 AUF3 32GB TruDDR4 Memory (4Rx4, 1.2V) PC4-17000 CL15 2133MHz LP LRDIMM 96 (24 per CPU) -
95Y4812 A5UK 64GB TruDDR4 Memory (4Rx4,1.2V) PC4-17000 CL15 2133MHz LP LRDIMM 96 (24 per CPU) -
DDR3 RDIMMs and LRDIMMs (for use with E7 v2 and v3 processors, except for 00D5024)
00D5024 A3QE 4GB (1x4GB, 1Rx4, 1.35V) PC3L-12800 CL11 ECC DDR3 1600MHz LP RDIMM 96 (24 per CPU) -
00D5036 A3QH 8GB (1x8GB, 1Rx4, 1.35V) PC3L-12800 CL11 ECC DDR3 1600MHz LP RDIMM 96 (24 per CPU) A4x, B1x, B3x,C1x, C4x, D4x
46W0672 A3QM 16GB (1x16GB, 2Rx4, 1.35V) PC3L-12800 CL11 ECC DDR3 1600MHz LP RDIMM 96 (24 per CPU) F1x, F3x, G1x,G3x
46W0676 A3SR 32GB (1x32GB, 4Rx4, 1.35V) PC3L-12800 CL11 ECC DDR3 1600MHz LP LRDIMM 96 (24 per CPU) -
46W0741 A451 64GB (1x64GB, 8Rx4, 1.35V) PC3-10600 DDR3 1333MHz LP LRDIMM 96 (24 per CPU) -
00D5024 is supported only in Compute Books with E7 v2 processors
00KH391 is supported only in Compute Books with E7-8880 v3 or E7-8890 v3 processors; no other memory DIMM is supported if 00KH391 is installed
Part number/Feature code/Description/Maximum supported
44X4104 A4A6 4x 2.5" HS 12Gb SAS HDD Backplane 2
44X4106 A4A7 8x 1.8" HS 12Gb SAS HDD Backplane 2
Drive combination/Backplanes required/Number of controllers supported
4x 2.5-inch hot-swap drive bays 1x 4x 2.5" HS 12Gb SAS HDD Backplane, 44X4104 1
8x 2.5-inch hot-swap drive bays 2x 4x 2.5" HS 12Gb SAS HDD Backplane, 44X4104 1
4x 2.5-inch hot-swap drive bays
8x 1.8-inch hot-swap SSD bays
1x 4x 2.5" HS 12Gb SAS HDD Backplane, 44X4104
1x 8x 1.8" HS 12Gb SAS HDD Backplane, 44X4106 2
8x 1.8-inch hot-swap SSD bays 1x 8x 1.8" HS 12Gb SAS HDD Backplane, 44X4106 1
16x 1.8-inch hot-swap SSD bays 2x 8x 1.8" HS 12Gb SAS HDD Backplane, 44X4106 2
陣列卡
46C9110 A3YZ ServeRAID M5210 SAS/SATA Controller 2 All models
47C8675 A3YY N2215 SAS/SATA HBA for System x 2 -
Hardware upgrades for the M5210
47C8656 A3Z0 ServeRAID M5200 Series 1GB Cache/RAID 5 Upgrade 2 -
47C8660 A3Z1 ServeRAID M5200 Series 1GB Flash/RAID 5 Upgrade 2 -
47C8664 A3Z2 ServeRAID M5200 Series 2GB Flash/RAID 5 Upgrade 2 -
47C8668 A3Z3 ServeRAID M5200 Series 4GB Flash/RAID 5 Upgrade 2 -
Features on Demand upgrades for the M5210
47C8708 A3Z6 ServeRAID M5200 Series Zero Cache/RAID 5 Upgrade 1 -
47C8706 A3Z5 ServeRAID M5200 Series RAID 6 Upgrade 1 -
47C8710 A3Z7 ServeRAID M5200 Series Performance Accelerator 1 -
47C8712 A3Z8 ServeRAID M5200 Series SSD Caching Enabler 1 -
硬盤
Part number/Feature code/Description/Maximum supported
1.8" 6 Gb SATA HS Enterprise SSDs
41Y8366 A4FS S3700 200GB SATA 1.8" MLC Enterprise SSD 16
41Y8371 A4FT S3700 400GB SATA 1.8" MLC Enterprise SSD 16
1.8" 6 Gb SATA HS Enterprise Value SSDs
00AJ455 A58U S3500 800GB SATA 1.8" MLC Enterprise Value SSD 16
00AJ335 A56V 120GB SATA 1.8" MLC Enterprise Value SSD 16
00AJ340 A56W 240GB SATA 1.8" MLC Enterprise Value SSD 16
00AJ345 A56X 480GB SATA 1.8" MLC Enterprise Value SSD 16
00AJ350 A56Y 800GB SATA 1.8" MLC Enterprise Value SSD 16
2.5" 6 Gb SAS HS SSDs
00AJ207 A4UA 200GB SAS 2.5" MLC G3HS Enterprise SSD 8
00AJ212 A4UB 400GB SAS 2.5" MLC G3HS Enterprise SSD 8
00AJ217 A4UC 800GB SAS 2.5" MLC G3HS Enterprise SSD 8
00AJ222 A4UD 1.6TB SAS 2.5" MLC G3HS Enterprise SSD 8
2.5" 6 Gb SAS Enterprise Capacity SSDs
00NA671 ASW6 3.84 TB 6 Gb SAS Enterprise Capacity G3HS MLC SSD 8
2.5" 6 Gb SATA HS Enterprise SSDs
00AJ156 A4U3 S3700 200GB SATA 2.5" MLC G3HS Enterprise SSD 8
00vAJ161 A4U4 S3700 400GB SATA 2.5" MLC G3HS Enterprise SSD 8
00AJ166 A4U5 S3700 800GB SATA 2.5" MLC G3HS Enterprise SSD 8
2.5" 6 Gb SATA HS Enterprise Value SSDs
00AJ395 A577 120GB SATA 2.5" MLC G3HS Enterprise Value SSD 8
00AJ400 A578 240GB SATA 2.5" MLC G3HS Enterprise Value SSD 8
00AJ405 A579 480GB SATA 2.5" MLC G3HS Enterprise Value SSD 8
00AJ410 A57A 800GB SATA 2.5" MLC G3HS Enterprise Value SSD 8
00FN278 A5U6 S3500 1.6TB SATA 2.5" MLC G3HS Enterprise Value SSD 8
2.5" 6 Gb SATA HS Entry SSDs
00FN337 AS0G 240GB SATA 2.5" MLC G3HS Entry SSD 8
00FN342 AS0H 480GB SATA 2.5" MLC G3HS Entry SSD 8
00FN347 AS0J 960GB SATA 2.5" MLC G3HS Entry SSD 8
2.5" 6 Gb NL SAS HS HDDs
00AJ121 A4TT 500GB 7.2K 6Gbps NL SAS 2.5" G3HS HDD 8
00AJ086 A4TU 1TB 7.2K 6Gbps NL SAS 2.5'' G3HS HDD 8
2.5" 6 Gb NL SATA HS HDDs
00AJ131 A4TV 250GB 7.2K 6Gbps NL SATA 2.5" G3HS HDD 8
00AJ136 A4TW 500GB 7.2K 6Gbps NL SATA 2.5" G3HS HDD 8
00AJ141 A4TX 1TB 7.2K 6Gbps NL SATA 2.5" G3HS HDD 8
2.5" 15K 6 Gb SAS HS HDDs
00AJ126 A4TS 600GB 15K 6Gbps SAS 2.5" G3HS HDD 8
00AJ081 A4TR 300GB 15K 6Gbps SAS 2.5" G3HS HDD 8
00AJ111 A4TQ 146GB 15K 6Gbps SAS 2.5" G3HS HDD 8
2.5" 10K 6 Gb SAS HS HDDs
00AJ146 A4TP 1.2TB 10K 6Gbps SAS 2.5" G3HS HDD 8
00AJ071 A4TN 900GB 10K 6Gbps SAS 2.5" G3HS HDD 8
00AJ091 A4TM 600GB 10K 6Gbps SAS 2.5" G3HS HDD 8
00AJ096 A4TL 300GB 10K 6Gbps SAS 2.5" G3HS HDD 8
2.5" 6 Gb SAS HS SEDs
00AJ116 A4U2 146GB 15K 6Gbps SAS 2.5" G3HS SED 8
00AJ106 A4TY 300GB 10K 6Gbps SAS 2.5" G3HS SED 8
00AJ101 A4TZ 600GB 10K 6Gbps SAS 2.5" G3HS SED 8
00AJ076 A4U0 900GB 10K 6Gbps SAS 2.5" G3HS SED 8
00AJ151 A4U1 1.2TB 10K 6Gbps SAS 2.5'' G3HS SED 8
2.5" 12 Gb SAS HS SSDs
00FN379 AS7C 200GB 12G SAS 2.5" MLC G3HS Enterprise SSD 8
00FN389 AS7E 400GB 12G SAS 2.5" MLC G3HS Enterprise SSD 8
00FN399 AS7G 800GB 12G SAS 2.5" MLC G3HS Enterprise SSD 8
00FN409 AS7J 1.6TB 12G SAS 2.5" MLC G3HS Enterprise SSD 8
2.5" 12 Gb SAS HS Enterprise SSD SEDs
00FN419 AS7L 400GB SED 12G SAS 2.5" MLC G3HS Enterprise SSD 8
00FN424 AS7M 800GB SED 12G SAS 2.5" MLC G3HS Enterprise SSD 8
2.5" 15K 12 Gb SAS HS HDDs
00NA221 ASBB IBM 300GB 15K 12Gbps SAS 2.5" G3HS 512e HDD 8
00NA231 ASBD IBM 600GB 15K 12Gbps SAS 2.5" G3HS 512e HDD 8
2.5" 10K 12 Gb SAS HS HDDs
00NA241 ASBF 600GB 10K 12Gbps SAS 2.5" G3HS 512e HDD 8
00NA251 ASBH 900GB 10K 12Gbps SAS 2.5" G3HS 512e HDD 8
00NA261 ASBK 1.2TB 10K 12Gbps SAS 2.5" G3HS 512e HDD 8
00NA271 ASBM 1.8TB 10K 12Gbps SAS 2.5" G3HS 512e HDD 8
2.5" 12 Gb SAS HS SEDs
00NA281 ASBP 300GB 15K 12Gbps SAS 2.5" G3HS 512e SED 8
00NA286 ASBQ 600GB 15K 12Gbps SAS 2.5" G3HS 512e SED 8
00NA291 ASBR 600GB 10K 12Gbps SAS 2.5" G3HS 512e SED 8
00NA296 ASBS 900GB 10K 12Gbps SAS 2.5" G3HS 512e SED 8
00NA301 ASBT 1.2TB 10K 12Gbps SAS 2.5" G3HS 512e SED 8
00NA306 ASBU 1.8TB 10K 12Gbps SAS 2.5" G3HS 512e SED 8
2.5" 15K 12 Gb SAS HS Hybrid HDDs
00NA311 ASBV 300GB 15K 12Gbps SAS 2.5" G3HS 512e Hybrid 8
00NA321 ASBX 600GB 15K 12Gbps SAS 2.5" G3HS 512e Hybrid 8
網卡
00D8540 A4XH Emulex Dual Port 10GbE SFP+ VFA IIIr for System x
49Y7960 A2EC Intel X520 Dual Port 10GbE SFP+ Adapter for System x
49Y7970 A2ED Intel X540-T2 Dual Port 10GBaseT Adapter for System x
49Y4230 5767 Intel Ethernet Dual Port Server Adapter I340-T2 for System x
49Y4240 5768 Intel Ethernet Quad Port Server Adapter I340-T4 for System x
00AG500 A56K Intel I350-F1 1xGbE Fiber Adapter for System x
00AG510 A56L Intel I350-T2 2xGbE BaseT Adapter for System x
00AG520 A56M Intel I350-T4 4xGbE BaseT Adapter for System x
I/O Book
Part number/Feature code/Description/Maximum supported
44X4049 A4A2 X6 Half-Length I/O Book 2
44X4051 A4A3 X6 Full-Length I/O Book 2
ML2 adapters
Part number/Feature code/Description/Maximum supported
00D2026 A40S Broadcom NetXtreme II ML2 Dual Port 10GbaseT for System x 1
00D2028 A40T Broadcom NetXtreme II ML2 Dual Port 10GbE SFP+ for System x 1
00D1996 A40Q Emulex VFA5 ML2 Dual Port 10GbE SFP+ Adapter for System x 1
00D8544 A4NZ Emulex VFA5 ML2 FCoE/iSCSI License for System x (FoD)(Features on Demand upgrade for 00D1996 - one for each
adapter) 1
00D1998 A40R Intel I350-T4 ML2 Quad Port GbE Adapter for System x 1
00D1994 A40P Intel X540 ML2 Dual Port 10GbaseT Adapter for System x 1
94Y5200 AS74 Intel X710 ML2 4x10GbE SFP+ Adapter for System x 1
00FP650 A5RK Mellanox ConnectX-3 Pro ML2 2x40GbE/FDR VPI Adapter for System x 1
40 Gb Ethernet
00D9550 A3PN Mellanox ConnectX-3 40GbE / FDR IB VPI Adapter for System x 9
10 Gb Ethernet
44T1370 A5GZ Broadcom NetXtreme 2x10GbE BaseT Adapter for System x 9
49Y7910 A18Y Broadcom NetXtreme II Dual Port 10GBaseT Adapter for System x 9
00JY820 A5UT Emulex VFA5 2x10 GbE SFP+ PCIe Adapter for System x 9
00JY830 A5UU Emulex VFA5 2x10 GbE SFP+ Adapter and FCoE/iSCSI SW for System x 9
00JY824 A5UV Emulex VFA5 FCoE/iSCSI SW for PCIe Adapter for System x (FoD) 9
00D8540 A4M9 Emulex Dual Port 10GbE SFP+ VFA III-R for System x 9
49Y7960 A2EC Intel X520 Dual Port 10GbE SFP+ Adapter for System x 9
49Y7970 A2ED Intel X540-T2 Dual Port 10GBaseT Adapter for System x 9
81Y3520 AS73 Intel X710 2x10GbE SFP+ Adapter for System x 9
00D9690 A3PM Mellanox ConnectX-3 10 GbE Adapter for System x 9
90Y4600 A3MR QLogic 8200 Dual Port 10GbE SFP+ VFA for System x 9
00Y5624 A3MT QLogic 8200 VFA FCoE/iSCSI License for IBM System x (FoD) 9
47C9952 A47H Solarflare SFN5162F 2x10GbE SFP+ Performant Adapter for System x 9
47C9960 A47J Solarflare SFN6122F 2x10GbE SFP+ Onload Adapter for System x 9
Gigabit Ethernet
00AG500 A56K Intel I350-F1 1xGbE Fiber Adapter for System x 9
00AG510 A56L Intel I350-T2 2xGbE BaseT Adapter for System x 9
00AG520 A56M Intel I350-T4 4xGbE BaseT Adapter for System x 9
90Y9370 A2V4 Broadcom NetXtreme I Dual Port GbE Adapter for System x 9
90Y9352 A2V3 Broadcom NetXtreme I Quad Port GbE Adapter for System x 9
49Y4230 5767 Intel Ethernet Dual Port Server Adapter I340-T2 for System x 9
49Y4240 5768 Intel Ethernet Quad Port Server Adapter I340-T4 for System x 9
InfiniBand
00D9550 A3PN Mellanox ConnectX-3 40GbE / FDR IB VPI Adapter for System x 9
光纖卡
Part number/Feature code/Description/Maximum supported
Fibre Channel - 16 Gb
81Y1655 A2W5 Emulex 16Gb FC Single-port HBA for System x 9
81Y1662 A2W6 Emulex 16Gb FC Dual-port HBA for System x 9
81Y1668 A2XU Brocade 16Gb FC Single-port HBA for System x 9
81Y1675 A2XV Brocade 16Gb FC Dual-port HBA for System x 9
00Y3337 A3KW QLogic 16Gb FC Single-port HBA for System x 9
00Y3341 A3KX QLogic 16Gb FC Dual-port HBA for System x 9
Fibre Channel - 8 Gb
42D0485 3580 Emulex 8 Gb FC Single-port HBA for System x 9
42D0494 3581 Emulex 8 Gb FC Dual-port HBA for System x 9
42D0501 3578 QLogic 8 Gb FC Single-port HBA for System x 9
42D0510 3579 QLogic 8 Gb FC Dual-port HBA for System x 9
46M6049 3589 Brocade 8 Gb FC Single-port HBA for System x 9
46M6050 3591 Brocade 8 Gb FC Dual-port HBA for System x 9
SAS
46C9010 A3MV N2125 SAS/SATA HBA for System x 9
00AE912 A5M0 N2225 SAS/SATA HBA for System x 9
固態 SSD adapters
Part number/Feature code/Description/Maximum supported
46C9078 A3J3 365GB High IOPS MLC Mono Adapter 9
46C9081 A3J4 785GB High IOPS MLC Mono Adapter 9
90Y4377 A3DY 1.2TB High IOPS MLC Mono Adapter 9
90Y4397 A3DZ 2.4TB High IOPS MLC Duo Adapter 9
00AE995 ARYP 1000GB Enterprise io3 Flash Adapter 6
00AE998 ARYQ 1300GB Enterprise io3 Flash Adapter 6
00JY004 ARYS 5200GB Enterprise io3 Flash Adapter 6
00JY001 ARYR 2600GB Enterprise io3 Flash Adapter 6
00AE983 ARYK 1250GB Enterprise Value io3 Flash Adapter 6
00AE986 ARYL 1600GB Enterprise Value io3 Flash Adapter 6
00AE989 ARYM 3200GB Enterprise Value io3 Flash Adapter 6
00AE992 ARYN 6400GB Enterprise Value io3 Flash Adapter 6
GPU adapters
Part number/Feature code/Description/Maximum supported
00FP670 A4G4 Intel Xeon Phi 3120A 12 GB 2
00J6160 A3GM NVIDIA GRID K1 32 GB 2
00FP674 A470 NVIDIA Grid K2 (Actively Cooled) 16 GB 2
00FP675 A3YU NVIDIA Quadro K4000 6 GB 2
00FP672 A3YV NVIDIA Quadro K6000 24 GB 2
00FP673 A471 NVIDIA Tesla K20 (Actively Cooled) 10 GB 2
00FP676 A5FG NVIDIA Tesla K40c 24 GB 2
電源 Power supplies
Part number/Feature code/Description/Maximum supported/Models where used
44X4150 A54D 1400W HE Redundant Power Supply for altitudes >5000 meters 4 All HANA models
44X4152 A54E 1400W HE Redundant Power Supply 4 -
44X4132 A4R0 900W Power Supply 4 A4x, B1x,B3x,C1x, C4x
88Y7433 A2EA 750W High Efficiency -48 V DC Power Supply 4 -
陣列卡 RAID controllers
Part number/Feature code/Description/Maximum supported/Models where used
00AE938 A5ND ServeRAID M5225-2GB SAS/SATA Controller 3 -
81Y4478 A1WX ServeRAID M5120 SAS/SATA Controller 2 -
Features on Demand upgrades for the M5225
47C8706 A3Z5 ServeRAID M5200 Series RAID 6 Upgrade for Systems-FoD 1
47C8710 A3Z7 ServeRAID M5200 Series Performance Accelerator for Systems-FoD 1
47C8712 A3Z8 ServeRAID M5200 Series SSD Caching Enabler for Systems-FoD 1
Hardware upgrades for the M5120
81Y4487 A1J4 ServeRAID M5100 Series 512MB Flash/RAID 5 Upgrade 1 -
81Y4559 A1WY ServeRAID M5100 Series 1GB Flash/RAID 5 Upgrade 1 -
47C8670 A4G6 ServeRAID M5100 Series 2GB Flash/RAID 5 Upgrade for System x 1
Feature on Demand upgrades for the M5120
90Y4318 A2MD ServeRAID M5100 Series SSD Caching Enabler 1 -
90Y4273 A2MC ServeRAID M5100 Series SSD Performance Key 1 -
81Y4546 A1X3 ServeRAID M5100 Series RAID 6 Upgrade 1 -
擴展柜 External expansion enclosures
Part number/Description/Maximum quantity supported per one controller
70F0 / 70F1 Lenovo ThinkServer SA120 8
610012X EXP2512 Express 18
610024X EXP2524 Express 9
External SAS cables for external storage expansion enclosures
Part number/Description/Maximum quantity supported per one enclosure
ServeRAID M5120 - Server to Expansion enclosure connectivity (Mini-SAS x4 to Mini-SAS x4)
39R6529 1 m SAS Cable 1
39R6531 3 m SAS Cable 1
ServeRAID M5225 - Server to Expansion enclosure connectivity (Mini-SAS HD x4 to Mini-SAS x4)
00MJ162 0.6m SAS Cable (mSAS HD to mSAS) 1
00MJ163 1.5m SAS Cable (mSAS HD to mSAS) 1
00MJ166 3m SAS Cable (mSAS HD to mSAS) 1
90Y7682 External Expansion Cable - 6M SAS Cable - HD SAS to Mini SAS 1
Expansion enclosure to Expansion enclosure connectivity (Mini-SAS x4 to Mini-SAS x4)
39R6529 1 m SAS Cable 1
39R6531 3 m SAS Cable 1
Drive options for EXP2512 external expansion enclosures
Part number/Description/Maximum quantity supported per one enclosure
3.5" NL SAS HS HDDs
00NC555 2TB 7,200 rpm 6Gb SAS NL 3.5" HDD 12
00NC557 3TB 7,200 rpm 6Gb SAS NL 3.5" HDD 12
00NC559 4TB 7,200 rpm 6Gb SAS NL 3.5" HDD 12
2.5" NL SAS HS HDDs
00NC571 1TB 7,200 rpm 6Gb SAS NL 2.5" HDD 24
2.5" SAS HS HDDs
00NC561 146GB 15,000 rpm 6Gb SAS 2.5" HDD 24
00NC563 300GB 15,000 rpm 6Gb SAS 2.5" HDD 24
00NC565 600GB 10,000 rpm 6Gb SAS 2.5" HDD 24
00NC567 900GB 10,000 rpm 6Gb SAS 2.5" HDD 24
00NC569 1.2TB 10,000 rpm 6Gb SAS 2.5" HDD 24
2.5" SAS HS SSDs
00NC573 200GB 6Gb SAS 2.5" SSD 24
00NC575 400GB 6Gb SAS 2.5" SSD 24
