安裝類型 |
機架式 |
|
高度 |
4U |
|
處理器系列 |
英特爾® 至強® E7-4800/8800 V2 系列 |
|
處理器緩存 |
37.5MB (1 x 37.5MB) Level 3 cache (E7-4890 v2, E7-8880Lv2, E7-4880v2, E7-8891v2, E7-8893v2)
30MB (1 x 30MB) Level 3 cache (E7-8857v2, E7-4870v2, E7-4860v2)
24MB (1 x 24MB) Level 3 cache (E7-4850v2)
20MB (1 x 20MB) Level 3 cache (E7-4830v2)
16MB (1 x 16MB) Level 3 cache (E7-4820v2)
12MB (1 x 12MB) Level 3 cache (E7-4809v2) |
|
處理器個數 |
最大4個 |
|
內存（最大） |
6TB |
|
內存插槽 |
內存插槽在內存板上，單個內存板有12個插槽，最多支持8個內存板，96個插槽 |
|
內存類型 |
DDR3 1600MHz/1333MHz/1066MHz |
|
擴展槽 |
Up to 9 slots supported; all full-length/full-height. Standard: 4 PCI-E 3.0 x8, 5 PCI-E 3.0 x16. |
|
網絡控制器 |
HPE Ethernet 1Gb 4-port 331FLR FIO Adapter
HPE Ethernet 1Gb 4-port 366FLR FIO Adapter
HPE Ethernet 10Gb 2-port 533FLR-T FIO Adapter
HPE FlexFabric 10Gb 2-port 534FLR-SFP+ FIO Adapter
NOTE: This adapter does not support FCOE Boot from SAN functionality on VMWare and FCOE
with RHEL 5.9.
HPE Ethernet 10Gb 2-port 560FLR-SFP+ FIO Adapter
HPE Ethernet 10Gb 2-port 561FLR-T FIO Adptr
HPE IB FDR/EN 40Gb 2P 544+FLR-QSFP Adptr
NOTE: For additional details see the Networking Section of this document.
NOTE: Wake-on-Lan feature is not supported on the DL580 Gen8 with FlexLOMs |
|
硬盤個數 |
最大10個SFF |
|
硬盤容量 |
Hot Plug SFF SAS 12 TB 10 x 1.2 TB
Hot Plug SFF SAS SSD 16 TB 10 x 1.6 TB
Hot Plug SFF SATA SSD 8 TB 10 x 800 GB |
|
電源類型 |
熱插拔冗余電源 |
|
電源個數 |
最大4個 |
|
電源功率 |
1200W/1500W |
|
操作系統 |
Windows Server 2012 R2 and Hyper-V 2012 R2
Windows Server 2012 (requires Microsoft hotfix 2901012) and Hyper-V 2012
Windows Server 2008 R2 and Hyper-V 2008 R2
Windows Server 2008 and Hyper-V 2008
Redhat Enterprise Linux 6.4
SLES 11 SP3 |
CPU
Fifteen-Core Processors
HP DL580 Gen8 Intel Xeon E7-4890v2 (2.8GHz/15-core/37.5MB/155W) FIO Processor Kit
728955-L21
HPE DL580 Gen8 Intel Xeon E7-4890v2 (2.8GHz/15-core/37.5MB/155W) Processor Kit
728955-B21
HP DL580 Intel Xeon E7-4880v2 (2.5GHz/15-core/37.5MB/130W) FIO Processor Kit
728957-L21
HPE DL580 Gen8 Intel Xeon E7-4880v2 (2.5GHz/15-core/37.5MB/130W) Processor Kit
728957-B21
HP DL580 Gen8 Intel Xeon E7-4870v2 (2.3GHz/15-core/30MB/130W) FIO Processor Kit
728959-L21
HPE DL580 Gen8 Intel Xeon E7-4870v2 (2.3GHz/15-core/30MB/130W) Processor Kit
728959-B21
HP DL580 Gen8 Intel Xeon E7-8880Lv2 (2.2GHz/15-core/37.5MB/105W) FIO Processor Kit
728953-L21
HPE DL580 Gen8 Intel Xeon E7-8880Lv2 (2.2GHz/15-core/37.5MB/105W) Processor Kit
728953-B21
Twelve-Core Processors
HP DL580 Gen8 Intel Xeon E7-4860v2 (2.6GHz/12-core/30MB/130W) FIO Processor Kit
728963-L21
HPE DL580 Gen8 Intel Xeon E7-4860v2 (2.6GHz/12-core/30MB/130W) Processor Kit
728963-B21
HP DL580 Gen8 Intel Xeon E7-4850v2 (2.3GHz/12-core/24MB/105W) FIO Processor Kit
728965-L21
HPE DL580 Gen8 Intel Xeon E7-4850v2 (2.3GHz/12-core/24MB/105W) Processor Kit
728965-B21
HP DL580 Gen8 Intel Xeon E7-8857v2 (3.0GHz/12-core/30MB/130W) FIO Processor Kit
728961-L21
HPE DL580 Gen8 Intel Xeon E7-8857v2 (3.0GHz/12-core/30MB/130W) Processor Kit
728961-B21
Ten-Core Processors
HP DL580 Gen8 Xeon E7-8891v2 (3.2GHz/10-core/37.5MB/155W) FIO Processor Kit
728967-L21
HPE DL580 Gen8 Intel Xeon E7-8891v2 (3.2GHz/10-core/37.5MB/155W) Processor Kit
728967-B21
HP DL580 Gen8 Xeon E7-4830v2 (2.2GHz/10-core/20MB/105W) FIO Processor Kit
728969-L21
HPE DL580 Gen8 Intel Xeon E7-4830v2 (2.2GHz/10-core/20MB/105W) Processor Kit
728969-B21
Eight-Core Processors
HP DL580 Gen8 Intel Xeon E7-4820v2 (2.0GHz/8-core/16MB/105W) FIO Processor Kit
728971-L21
HPE DL580 Gen8 Intel Xeon E7-4820v2 (2.0GHz/8-core/16MB/105W) Processor Kit
728971-B21
Six-Core Processors
HP DL580 Gen8 Intel Xeon E7-4809v2 (1.9GHz/6-core/12MB/105W) FIO Processor Kit
728975-L21
HPE DL580 Gen8 Intel Xeon E7-4809v2 (1.9GHz/6-core/12MB/105W) Processor Kit
728975-B21
HP DL580 Gen8 Intel Xeon E7-8893v2 (3.4GHz/6-core/37.5MB/155W) FIO Processor Kit
728973-L21
HPE DL580 Gen8 Intel Xeon E7-8893v2 (3.4GHz/6-core/37.5MB/155W) Processor Kit
728973-B21
內存
Registered DIMMs (RDIMMs)
HPE 8GB (1x8GB) Single Rank x4 PC3-14900R (DDR3-1866) Registered CAS-13 Memory Kit
731761-B21
HPE 8GB (1x8GB) Single Rank x4 PC3L-12800R (DDR3-1600) Registered CAS-11 Low Voltage Memory Kit
731765-B21
HPE 16GB (1x16GB) Dual Rank x4 PC3-14900R (DDR3-1866) Registered CAS-13 Memory Kit
708641-B21
HPE 16GB (1x16GB) Dual Rank x4 PC3L-12800R (DDR3-1600) Registered CAS-11 Low Voltage Memory Kit
713985-B21
Load Reduced DIMMs (LRDIMMS)
HPE 32GB (1x32GB) Quad Rank x4 PC3-14900L (DDR3-1866) Load Reduced CAS-13 Memory Kit
708643-B21
HP 64GB (1x64GB) Octa Rank x4 PC3-12800L (DDR3-1600) Load Reduced CAS-11 Memory Kit
700838-B21
Memory Expansion Options
HP DL580 Gen8 12 DIMM Slots Memory Cartridge
732411-B21
硬盤
12G SAS Hot Plug with SmartDrive SFF (2.5-inch) Enterprise Drives
HPE 600GB SAS 12G Enterprise 15K SFF (2.5in) SC 3yr Wty HDD 759212-B21
HPE 450GB SAS 12G Enterprise 15K SFF (2.5in) SC 3yr Wty HDD 759210-B21
HPE 300GB SAS 12G Enterprise 15K SFF (2.5in) SC 3yr Wty HDD 759208-B21
12G SAS Hot Plug with SmartDrive SFF (2.5-inch) Enterprise Drives
HPE 1.2TB SAS 12G Enterprise 10K SFF (2.5in) SC 3yr Wty HDD 781518-B21
HPE 900GB SAS 12G Enterprise 10K SFF (2.5in) SC 3yr Wty HDD 785069-B21
HPE 600GB SAS 12G Enterprise 10K SFF (2.5in ) SC 3yr Wty HDD 781516-B21
HPE 300GB SAS 12G Enterprise 10K SFF (2.5in) SC 3yr Wty HDD 785067-B21
12G SAS Hot Plug SFF (2.5-inch) SC HDD
HPE 1.8TB SAS 12G Enterprise 10K SFF (2.5in) SC 3yr Wty 512e HDD 791034-B21
12G SAS Hot Plug SFF (2.5-inch) SC SSD
HPE 1.92TB SAS 12G Read Intensive SFF (2.5in) SC 3yr Wty SSD 802891-B21
HPE 800GB SAS 12G Write Intensive SFF (2.5in) SC 3yr Wty SSD 802586-B21
HPE 400GB SAS 12G Write Intensive SFF (2.5in) SC 3yr Wty SSD 802582-B21
HPE 200GB SAS 12G Write Intensive SFF (2.5in) SC 3yr Wty SSD 802578-B21
12G SAS SFF (2.5in) RI-3 SC Solid State Drives
HPE 3.84TB SAS 12G Read Intensive SFF (2.5in) SC 3yr Wty SSD 816576-B21
HPE 1.92TB SAS 12G Read Intensive SFF (2.5in) SC 3yr Wty SSD 816572-B21
HPE 960GB SAS 12G Read Intensive SFF (2.5in) SC 3yr Wty SSD 816568-B21
HPE 480GB SAS 12G Read Intensive SFF (2.5in) SC 3yr Wty SSD 816562-B21
12G SAS SFF (2.5in) MU-3 SC Solid State Drives
HPE 3.2TB SAS 12G Mixed Use SFF (2.5in) SC 3yr Wty SSD 822567-B21
HPE 1.6TB SAS 12G Mixed Use SFF (2.5in) SC 3yr Wty SSD 822563-B21
HPE 800GB SAS 12G Mixed Use SFF (2.5in) SC 3yr Wty SSD 822559-B21
HPE 400GB SAS 12G Mixed Use SFF (2.5in) SC 3yr Wty SSD 822555-B21
12G SAS Hot Plug SFF (2.5-inch) SC HDD
HPE 2TB SAS 12G Midline 7.2K SFF (2.5in) SC 1yr Wty 512e HDD 765466-B21
HPE 1TB SAS 12G Midline 7.2K SFF (2.5in) SC 1yr Wty 512e Digitally Signed Firmware HDD 765464-B21
HPE 600GB SAS 12G Enterprise 15K SFF (2.5in) SC 3yr Wty 512e HDD 748387-B21
6G SAS Hot Plug with SmartDrive SFF (2.5-inch) Enterprise Drives
HP 1.2TB 6G SAS 10K rpm SFF (2.5-inch) SC Dual Port Enterprise 3yr Warranty Hard Drive 718162-B21
HP 900GB 6G SAS 10K rpm SFF (2.5-inch) SC Enterprise 3yr Warranty Hard Drive 652589-B21
HP 600GB 6G SAS 10K rpm SFF (2.5-inch) SC Enterprise 3yr Warranty Hard Drive 652583-B21
HP 450GB 6G SAS 10K rpm SFF (2.5-inch) SC Enterprise 3yr Warranty Hard Drive 652572-B21
HP 300GB 6G SAS 10K rpm SFF (2.5-inch) SC Enterprise 3yr Warranty Hard Drive 652564-B21
HP 300GB 6G SAS 15K rpm SFF (2.5-inch) SC Enterprise 3yr Warranty Hard Drive 652611-B21
HP 146GB 6G SAS 15K rpm SFF (2.5-inch) SC Enterprise 3yr Warranty Hard Drive 652605-B21
6G SAS Hot Plug SmartDrive SFF (2.5-inch) Midline Drives
HPE 1TB 6G SAS 7.2K rpm SFF (2.5-inch) SC Midline 1yr Warranty Hard Drive 652749-B21
HPE 500GB 6G SAS 7.2K rpm SFF (2.5-inch) SC Midline 1yr Warranty Hard Drive 652745-B21
HPE 200GB SAS 12G Write Intensive SFF (2.5in) SC 3yr Wty SSD 779164-B21
HPE 400GB SAS 12G Write Intensive SFF (2.5in) SC 3yr Wty SSD 779168-B21
HPE 800GB SAS 12G Write Intensive SFF (2.5in) SC 3yr Wty SSD 779172-B21
HPE 1.6TB SAS 12G Write Intensive SFF (2.5in) SC 3yr Wty SSD 779176-B21
12G SAS SFF (2.5-in) MDL SC HDD
HPE 1TB SAS 12G Midline 7.2K SFF (2.5in) SC 1yr Wty Digitally Signed Firmware HDD 832514-B21
6G SATA 2.5in WI-PLP SC Solid State Drives
HPE 1.2TB SATA 6G Write Intensive SFF (2.5in) SC 3yr Wty SSD 804677-B21
HPE 800GB SATA 6G Write Intensive SFF (2.5in) SC 3yr Wty SSD 804671-B21
HPE 400GB SATA 6G Write Intensive SFF (2.5in) SC 3yr Wty SSD 804665-B21
HPE 200GB SATA 6G Write Intensive SFF (2.5in) SC 3yr Wty SSD 804639-B21
6G SATA 2.5in MU-PLP SC Solid State Drives
HPE 1.6TB SATA 6G Mixed Use SFF (2.5in) SC 3yr Wty SSD 804631-B21
HPE 800GB SATA 6G Mixed Use SFF (2.5in) SC 3yr Wty SSD 804625-B21
HPE 480GB SATA 6G Mixed Use SFF (2.5in) SC 3yr Wty SSD 832414-B21
HPE 200GB SATA 6G Mixed Use SFF (2.5in) SC 3yr Wty SSD 804613-B21
6G SATA 2.5in RI-PLP SC Solid State Drives
HPE 1.6TB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty SSD 804605-B21
HPE 800GB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty SSD 804599-B21
HPE 480GB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty SSD 804593-B21
HPE 240GB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty SSD 804587-B21
HPE 120GB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty SSD 804581-B21
HPE 80GB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty SSD 804575-B21
6G SATA Hot Plug SFF (2.5-inch) SC HDD
HPE 2TB SATA 6G Midline 7.2K SFF (2.5in) SC 1yr Wty 512e Digitally Signed Firmware HDD 765455-B21
HPE 1TB SATA 6G Midline 7.2K SFF (2.5in) SC 1yr Wty 512e Digitally Signed Firmware HDD 765453-B21
6G SATA Hot Plug SFF (2.5-inch) RI SC Solid State Drives
HP 480GB 6G SATA Read Intensive SFF 2.5-in SC 3yr Wty Solid State Drive 789145-B21
6G SATA Value Endurance Hot Plug SFF (2.5-inch) Enterprise Value Solid State Drives
HP 600GB 6G SATA Value Endurance SFF 2.5-in SC Enterprise Value 3yr Wty Solid State Drive 739898-B21
6G SATA Hot Plug SFF (2.5-inch) SC Midline HDD
HPE 1TB SATA 6G Midline 7.2K SFF (2.5in) SC 1yr Wty Digitally Signed Firmware HDD 655710-B21
HPE 500GB 6G SATA 7.2K rpm SFF (2.5-inch) SC Midline 1yr Warranty Hard Drive 655708-B21
6G SATA Value Endurance Hot Plug SFF (2.5-inch) SC Enterprise Value M1 SSD
HPE 120GB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty SSD 764923-B21
HPE 240GB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty SSD 764925-B21
HPE 480GB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty SSD 764927-B21
HPE 800GB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty SSD 764929-B21
6G SATA Value Endurance Hot Plug SFF (2.5-inch) SC Enterprise Value G1 SSD
HP 480GB 6G SATA Value Endurance SFF 2.5-in SC Enterprise Value 3yr Wty G1 Solid State Drive 756657-B21
6G SATA Hot Plug RI-3 SFF (2.5-inch) SC Solid State Drives
HPE 3.84TB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty SSD 816929-B21
HPE 1.92TB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty SSD 816919-B21
HPE 960GB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty SSD 816909-B21
HPE 480GB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty SSD 816899-B21
HPE 240GB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty SSD 816889-B21
HPE 120GB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty SSD 816879-B21
6G SATA Hot Plug MU-3 SFF (2.5-inch) SC Solid State Drives
HPE 1.92TB SATA 6G Mixed Use SFF (2.5in) SC 3yr Wty SSD 817011-B21
HPE 960GB SATA 6G Mixed Use SFF (2.5in) SC 3yr Wty SSD 816995-B21
HPE 480GB SATA 6G Mixed Use SFF (2.5in) SC 3yr Wty SSD 816985-B21
HPE 240GB SATA 6G Mixed Use SFF (2.5in) SC 3yr Wty SSD 816975-B21
HPE 120GB SATA 6G Mixed Use SFF (2.5in) SC 3yr Wty SSD 816965-B21
12G SAS Enterprise Performance, Mainstream and Value Solid State Drives
HP 1.6TB 12G SAS Value Endurance SFF 2.5-in SC Enterprise Value 3yr Wty Solid State Drive 762263-B21
HPE 800GB SAS 12G Read Intensive SFF (2.5in) SC 3yr Wty SSD 762261-B21
硬盤背板
HP ProLiant DL580 5 Small Form Factor Drive Backplane Cage Kit 739405-B21
HPE Small Form Factor Hard Drive Blank Kit 666987-B21
HP DL580 PCIe Stand-up SAS Controller Upper Drive Backplane Cable Kit 748916-B2
陣列卡
HPE Smart Array P830/4GB FBWC 12Gb 2-ports Int PCIe x8 SAS Controller 698533-B21
HPE Smart Array P430/4GB FBWC 12Gb 1-port Int SAS Controller 698530-B21
HPE Smart Array P430/2GB FBWC 12Gb 1-port Int SAS Controller 698529-B21
網卡
HPE Ethernet 1Gb 4-port 331FLR FIO Adapter 684208-B21
HPE Ethernet 1Gb 4-port 366FLR FIO Adapter 684217-B21
HPE FlexFabric 10Gb 2-port 556FLR-SFP+ FIO Adapter 732456-B21
HPE Ethernet 10Gb 2-port 560FLR-SFP+ FIO Adapter 684218-B21
HP Ethernet 10Gb 2-port 561FLR-T FIO Adapter 700700-B21
HPE InfiniBand FDR/Ethernet 10Gb/40Gb 2-port 544+FLR-QSFP Adapter 764285-B21
網卡
10 Gigabit Ethernet Adapters
HPE Ethernet 10Gb 2-port 561T Adapter 716591-B21
FlexibleLOM Adapters
HP Ethernet 1Gb 4-port 331FLR Adapter 629135-B21
HPE Ethernet 1Gb 4-port 366FLR Adapter 665240-B21
HPE Ethernet 10Gb 2-port 546SFP+ Adapter 779793-B21
HPE Ethernet 10Gb 2-port 546FLR-SFP+ Adapter 779799-B21
HPE Ethernet 10Gb 2-port 560FLR-SFP+ Adapter 665243-B21
HPE InfiniBand FDR/Ethernet 10Gb/40Gb 2-port 544+FLR-QSFP Adapter 764285-B21
HPE Ethernet 10Gb 2-port 557SFP+ Adapter 788995-B21
電源
HPE Common Slot Platinum Plus Power Supply Kits
HPE 1500W Common Slot Platinum Plus Power Supply Kit 684532-B21
HPE 1200W Common Slot Platinum Plus Hot Plug Power Supply Kit 656364-B21
顯卡
NVIDIA Quadro K6000 PCI-E Graphics Adapter 730874-B21
NVIDIA Tesla K40C 12GB Computational Accelerator 753960-B21
NVIDIA GRID K2 Reverse Air Flow Dual GPU PCIe Graphics Accelerator 753958-B21
Disk Enclosures
HP D2600 w/12 4TB 6G SAS 7.2K LFF Dual Port MDL HDD 48TB Bundle E7W32A
HPE Converged Network Adapters
HPE StoreFabric CN1100R Dual Port Converged Network Adapter QW990A
HPE StoreFabric CN1200E 10Gb Converged Network Adapter E7Y06A
HPE Infiniband Options
HPE InfiniBand FDR/Ethernet 10Gb/40Gb 2-port 544+QSFP Adapter 764284-B21
HPE InfiniBand QDR/Ethernet 10Gb 2-port 544+FLR-QSFP Adapter 764286-B21
HPE InfiniBand FDR/Ethernet 10Gb/40Gb 2-port 544+FLR-QSFP Adapter 764285-B21
HPE InfiniBand FDR 2-port 545QSFP Adapter 702211-B21
光纖卡
QLogic Fibre Channel HBAs
HPE 81Q 8Gb 1-port PCIe Fibre Channel Host Bus Adapter AK344A
HPE 82Q 8Gb 2-port PCIe Fibre Channel Host Bus Adapter AJ764A
HPE StoreFabric SN1000Q 16GB 1-port PCIe Fibre Channel Host Bus Adapter QW971A
HPE StoreFabric SN1000Q 16GB 2-port PCIe Fibre Channel Host Bus Adapter QW972A
Emulex Fibre Channel HBAs
HPE 81E 8Gb 1-port PCIe Fibre Channel Host Bus Adapter AJ762B
HPE 82E 8Gb 2-port PCIe Fibre Channel Host Bus Adapter AJ763B
HPE StoreFabric SN1100E 16Gb Single Port Fibre Channel Host Bus Adapter C8R38A
HPE StoreFabric SN1100E 16Gb Dual Port Fibre Channel Host Bus Adapter C8R39A
